Elysia xfilter 500
- 100% Class-A topology
- True stereo link
- High and low shelf filter
- Resonance-capable highpass and lowpass filter
- Two parametric mids with switchable Q
- Additional passive high band
- Stepped potentiometer (computer-selected)
- Special low tolerance capacitors
- Continuous mass shield
- Frequency range: < 10 Hz - 400 kHz (-3.0 dB)
- Noise: 20 Hz - 20 kHz - 98 dBu
- Dynamic range: 20 Hz - 22 kHz 120 dB
- Maximum level input/output: +21 dBU
- Input impedance 10 kOhm
- Output impedance 68 Ohm
- Includes: xfilter 500 module without frame
- Construction: API Series 500 format
|48 V Phantom power||No|
