Drum Module
- 120 GB solid state hard drive
- 60 pre-installed Steven Slate Drums 5 drum sounds
- 24 bit multi-layer samples
- Burr Brown converter
- WAV / AIFF samples import (length up to 20 seconds)
- Integrated single-channel control for close, overhead and room microphones
- 7 "IPS multi-touch screen
- Universal knob for fine adjustments
- Independent from line outputs headphone mixer
- Metronome
- Effects section with compressor, equalizer and reverb, adjustable for each channel, as well as without reverb for the headphone output
- Setlist function allows storing kits and metronomes in a list
- Song player plays WAV files from USB stick
- 16 trigger inputs 6.3 mm stereo jack
- 6 line outputs 6.3 mm mono jack
- 8 Additional outputs through separately available DB25 cable whip (e.g. item number 426511)
- Headphone output 6.3 mm stereo jack
- Line input stereo 1/4 " jacks
- SD card slot
- USB 2.0
- RJ45 (Ethernet) port for future expansion
- MIDI In and Out
- Compatible with almost any E-drum pad and cymbal (also 2- or 3-zone cymbals)
- Each input supports cymbal choke
- Including power supply
Available since
October 2017
Item number
423043
Sales Unit
1 piece(s)
Number of Trigger inputs
16
Direct Outputs
6
Integrated Metronome
Yes
Sampling Function
Yes
MIDI Interface
Yes
USB connector
Yes
Mix Input
Yes
