Roland System-1m

Semi-Modular Synthesizer Incl. PLUG-OUT Function

  • 19 Colour codes for CV/gate and audio connectors
  • With LED lighting
  • Compatible with desktop designs - compatible with 84 HP Eurorack and 19" rack
  • Power by AC adapter or Eurorack power bus
  • 64 Sets: 8 banks x 8 patches
  • Versatile oscillators with 6 waveforms
  • Crossmod
  • Ring Mod
  • Sync and colour control
  • Control of all parameters using high-resolution rotary knobs and sliders with LED indicators
  • Audio input
  • Filter, amp and FX sections for external audio signal
  • -12 dB and -24 dB filter types with independent high-pass filters
  • Built-in effects (tone, crusher, reverb, delay)
  • Tempo sync for LFO and delay effects
  • 24-bit / 96kHz audio and MIDI interface
  • AIRA Link interface for easy connection to MX-1 Mix Performer
  • Dimensions (L x W x H): 427 x 129 x 70 mm
  • Weight: 1.25 kg
  • Incl. AC adapter, PLUG-OUT information card, rack adapters, Eurorack installation screws, Eurorack power cable, patch cable with braided fabric coating (Set of three cables)

Connections:

  • Phones plug: Stereo mini-jack
  • Output (L / MONO, R) plug: jack (back)
  • Output (L / MONO, R) plug: mini-jack (front)
  • LFO Out
  • OSC 1 SYNC Out
  • OSC 2 SYNC In
  • Ring In
  • OSC 1 Out
  • OSC 2 Out
  • Ext In
  • Mix Out
  • Pitch ENV In
  • Filter ENV In
  • Filter ENV Out
  • Filter LFO In
  • Gate In
  • CV In
  • Amp ENV In
  • Amp ENV Out plug: mini jack
  • MIDI (In, Out) connection (back and bottom)
  • USB connection: USB type B (Audio / MIDI)
  • DC IN jack
No JavaScript? No Audio Samples! :-(

Audio Examples


0:00
  • Sequence 1
  • Sequence 2
  • Sequence 3
  • Sequence 4

Further Information

Design 19"
Polyphony 4
Sound Generation Modeling
MIDI interface 1x In, 1x Out
Storage Medium Internal
USB-port Yes
Effects Yes
Arpeggiator No
Number of Analog Outputs 2
Digital Output No
Display No

This product is currently sold out

These are other customers' choices:

Behringer Crave
13% bought Behringer Crave $155
Behringer NEUTRON
11% bought Behringer NEUTRON $289
Behringer Pro-1
10% bought Behringer Pro-1 $258
Behringer TD-3-SR
9% bought Behringer TD-3-SR $111
Moog DFAM
9% bought Moog DFAM $585
Our most popular Sound Modules
23 Customer Ratings
  • 5
  • 4
  • 3
  • 2
  • 1
4.5 /5
  • handling
  • features
  • sound
  • quality
Total
handling
features
sound
quality
Plug-out support
Captain Pungent, 27.05.2019
I bought this specifically for the plug-out functionality. It can only load ONE plug-out synth at a time, and it only works with SH-101, SH-2 and PROMARS. Unfortunately that information is not available anywhere, so I thought to share with you here.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
handling
features
sound
quality
Thank You!
11.01.2017
Greetings! Just purchase the Roland system 1m a Semi Modular Synth and have to say that that is very funny to to play!
I'm starting to create some experimental Psy-Trance music and the system 1m help me a lot creating cosmic ambients, build ups and drops from the LFO.
I just found some troubles in the LFO Rate which are no separate from bars, but at the same time is good to create more natural movement!
I like a lot the sound of the wave tables it sound very interesting!
Thanks a lot to help me in my mission on Earth!
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
de Original review (Show translation)
Unfortunately there was an error. Please try again later.
Total
handling
features
sound
quality
Für mich ein Rückschritt
26.01.2016
Ich hatte mir zu meinem Sequentix Cirklon eine Klangquelle mit möglichst direkter Erreichbarkeit aller Parameter über das Frontpanel gewünscht. System-1m scheint das zu bieten. Ferner haben mich einige Youtube-Videos fasziert, in denen das System in einen modularen Aufbau eingebunden wird. Tests und Bewertungen versprechen auch nur Gutes.
Beim "Spielen" am Gerät hat mich aber bald gestört, daß ich die eingestellten Werte nicht sehen kann. Ich hatte mir das nicht so extrem vorgestellt, aber man tappt doch arg im Dunkeln. Dazu kommt, daß es nur Potis und Fader gibt. Man dreht oder schiebt also erst 'mal ein Stück, bis sich etwas tut. War's der falsche Dreh, dann weiß man nicht mehr, wie's eingestellt war. Kein Weg zurück. Um zu kontrollieren, ob ich mich nur zu doof anstelle, habe ich meinen altem Waldorf MicroQ reaktiviert und ein bißchen daran "geschraubt". So soll's sein: Ein erster Dreh am Knopf zeigt erst 'mal, wo man ist. Erst wenn man weiterdreht, verändert sich auch der Parameter. Der selbstverständlich im Display zu sehen ist. Als jemand, der selbst in der Elektronikentwicklung aktiv ist, frage ich mich, wieso das heute nicht alle so machen. Bei einem vollanalogen Gerät sehe ich ja die Potis noch ein, aber hier werden die Potistände nur von einem Microcontroller abgefragt und verarbeitet. Der kommt mit Encodern genauso klar. Und die kosten im Einkauf nur ein paar Cent mehr als Potis.
Vielleicht ist der Klang des System-1m "analoger" als der des MicroQ, aber das ist für mich nicht wichtig. Für mich zählt die intuitive, schnelle Bedienung. Und die sehe ich beim Roland-Gerät nicht. Das bremst den kreativen Prozess.
Ach ja: Ich habe festgestellt, daß der VCA-Ausgangspegel so hoch werden kann, daß der Hall-Effekt übersteuert. Vielleicht wird das mit dem Systemupdate abgestellt? Habe ich dann nicht mehr ausprobiert.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
fr Original review (Show translation)
Unfortunately there was an error. Please try again later.
Total
handling
features
sound
quality
System-1m: Semi modulaire complet et performant
25.04.2016
Avantages:
Cet appareil offre l'ensemble des fonctionnalités nécessaires à créer un son, le moduler, l'interconnecter (midi; signaux CV et audio), mémoriser les réglages et les rappeler, échanger et restructurer des bibliothèques de sons via un PC pour une utilisation ordonnée. En plus, les effets réverbération et délais permettent de finaliser uniquement avec cet appareil, le son dans un espace (même si c'est sommaire).
Belle finition agréable à l'oeil avec les leds lumineuses.

Inconvénients:
Quand on rappelle un setup sonore via la banque archivée dans l'appareil, il sonne comme prévu, mais les réglages des boutons ne correspondent pas. ceci doit-être traité à l'aide d'une application sur ordinateur qui communique via le cordon USB. à confirmer.
La documentation Roland est très sommaire. Seul un "Quick Manual référence" est disponible. Un synoptique de l'appareil serait un plus pour une meilleure compréhension.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
$599
The shipping costs are calculated on the checkout page.
In stock within 7-9 weeks
In stock within 7-9 weeks

This item is expected back in stock soon and can then be shipped immediately.
