Waldorf KB37 Keyboard

Keyboard for Eurorack modules

  • Fatar TP9 keyboard with 37 keys and aftertouch
  • Pitchbend- and modulation wheel, glide, octave up/down switch
  • Gate retrigger
  • CV interface: 8 CV outputs, pitch, velocity, aftertouch, pitchbend, mod wheel
  • 3 freely definable MIDI controllers
  • 3 trigger outputs
  • Gate
  • Clock & Reset outputs for MIDI synchronisation
  • Module section: Eurorack compatible bus
  • Integrated power supply: +12 V / -12 V / 1.5 A
  • Width: 545 mm / 107 HP
  • USB
  • MIDI In / Out / Thru
  • Sustain pedal input
  • Sensor input and output
  • 2 line outputs: L/R stereo
  • 6.3 mm jack stereo headphone output
  • Dimensions: 656 mm x 122 mm x 334mm (W x H x D)
  • Weight: 8.5 kg

Note: Eurorack modules are not included.

Further Information

System Eurorack
Width 107 TE / HP
Hight 3 U
Power Supply Yes
Formfactor Keyboard
11 Customer Ratings
  • 5
  • 4
  • 3
  • 2
  • 1
4.7 /5
  • features
  • quality
Total
Almost the ideal Euro case
Giles J., 18.02.2017
I wanted a Euro case with a keyboard since having modules in a case and then needing an external keyboard is a lot of faff.

The kb37 is pretty much the only big name option at the time of reviewing and is a great option. The keybed is a Fatar, it's not weighted but it at least has aftertouch.

Having all the modulation options as CV outs is very useful, as is having full 1/4 inch jacks for sound output.

The only negatives for me are that the power outputs are unshrouded and bunched up to the left of the case. Also the power supply reduces the available space for the rightmost module.

I like this enough to have two of them and would consider buying more. I like to group my modules into a full synth rather than have a huge rack of modules.
