Zoom LiveTrak L-12

270

Start 360°

Please activate your javascript. You’re currently missing out on our lovely designed product gallery and its useful features (zoom into the very last pixel of each picture, 360 view, videos and more). We wouldn’t miss them for the world.

Combined mixer, audio interface and recorder

12 Discrete channels (8 mono plus 2 stereo channels) with XLR and 6.3 mm jack sockets
Simultaneous recording of up to 14 tracks
Playback of 12 tracks
24-Bit USB audio interface with 14 inputs and 4 outputs
Sampling frequency: 44.1 / 48/96 kHz
Five powerful headphone outputs with individually adjustable monitor mixes
Expand your livestream and recording with backing and click tracks from the computer
Line inputs in RCA and TS jack format
48 V phantom power: channels 1 to 4 and 5 to 8
Hi-Z connections: channels 1 and 2
26 dB pad: channels 3 to 8
Integrated compressor controller: channels 1 to 8
Master mute button
High-pass regulator
Adjustable stereopanorama
Master and monitor outputs AE
Memory function for up to nine mixers
16 Internal, editable delay and hall effects
Integrated talkback microphone
Class-Compliant operation (for iOS compatibility)
SD-card slot
Internal metronome
Ability to automatically start and stop recording
Project protection function
Import and export projects via the USB 2.0 interface
Latency compensation for AD conversion
Compatible functions for the ZOOM FS01 foot switch
Includes: power supply (AD-19), USB 2.0 cable and short manual
Dimensions (W x D x H): 445 x 282 x 70.5 mm
Weight: 2.53 kg
Suitable optional case: Art.492951 (not included)

30 30-Day Money-Back Guarantee

3 3-Year Thomann Warranty

available since September 2017

Item number 419407

sales unit 1 piece(s)

Recording / Playback Channels 14x4

Number of Mic Inputs 8

Number of Line Inputs 12

Number of Instrument Inputs 2

Number of Line Outs 6

Headphone Outs 4

Phantom power Yes

Number of S/PDIF Connectors 0

Number of ADAT Connectors 0

Numer of AES/EBU Connectors 0

Number of MADI Connectors 0

Ethernet 0

Other Connectors No

MIDI interface No

Word Clock No

Max. sample rate (kHz) 96 kHz

Max. resolution in bit 24 bit

USB Bus-Powered No

Incl. power supply Yes

USB Version 2.0

Width in mm 445 mm

Depth in mm 282 mm

Height in mm 70,5 mm

Connection Format USB port Type B, Type A

User Interface Physical

Number Of Tracks 12

Number of faders 12

Simultaneous Recording: Amount Of Tracks 14

DSP Input channels 12

Effects 1

Storage Medium SD Card, USB

DSP Output Channels 6

Busses 6

Mic Preamp 8

XLR Connectors 8

Jack Connectors 4

Mono-Line Input 8

Stereo-Line Input 2

RCA Connectors 1

MIDI Interface None

Physical outputs 9

USB connection 1

Digital stagebox connection No

Digital Connections None

Miscellaneous Connectors Control In

Hotspot No

Headphone connection 1

Multitrack Record Yes

Soundcard interface USB-B

Options Audiointerface, Compressor

integratated Player/Rec via USB/SD Multitrack

Recorder Format WAV

RTA No

FX Processor 1

31 Band EQ 0

Matrix 0

DCA/VCA Gruppen 0

Midi Connector No

Sample rate 44,1/48/96 kHz

Separate Personal Monitor system No

Expansion Card slots 0

Digital ADAT No

Digital SPDIF No

Included in delivery Power Supply

Digital AES3/ASESEB No

Digital MADI No

Zero latency monitoring 1

Digital Dante No

110V capable 1

Case No

19" Rackmount No

Height 70 mm

Width 445 mm

Depth 282 mm

Weight 2,5 kg

Show variations of this product

270

Zoom LiveTrak L-12

Zoom LiveTrak L-12 Combined mixer, audio interface and recorder * 12 Discrete channels (8 mono plus 2 stereo channels) w...

$559

to the product

105

Zoom LiveTrak L-20

Zoom LiveTrak L-20 Combined Mixer, Audio Interface and Recorder * 20 Discrete channels * 16 Mono plus 2 stereo channels ...

$888

to the product

Zoom LiveTrak L-8

Zoom LiveTrak L-8 Compact Podcast Mixer, Audio Interface and Recorder * 8-Channel mixer * Channels 1-2 for microphone, l...

$385

to the product

Zoom PodTrak P4

Zoom PodTrak P4 Podcasting Recorder * Four microphone inputs (XLR, P48V phantom power switchable) * Four headphone outpu...

$159

to the product

Zoom LiveTrak L-20R

Zoom LiveTrak L-20R Rack-Mountable Digital Mixer, Audio Interface and Recorder * 20 Input channels: 16 Mono- and 2 stere...

$599

to the product

Zoom PodTrak P8

Zoom PodTrak P8 Podcasting Recorder * Colour LCD touch screen * 6 Microphone inputs with XLR connections and optional ph...

$422

to the product

Zoom AMS-44

Zoom AMS-44 USB 2.0 Audio Interface * 24-bit / 96 kHz * Four microphone and line inputs XLR/TRS combo jack with max. +58...

$149

to the product

Zoom AMS-24

Zoom AMS-24 USB 2.0 Audio Interface * 24-bit / 96 kHz * Two microphone and line inputs XLR/TRS combo jack with max. +58d...

$105

to the product

Zoom AMS-22

Zoom AMS-22 USB 2.0 Audio Interface * 24-bit / 96 kHz * Microphone and instrument input XLR/TRS combo jack with max. +54...

$76

to the product

$559

The shipping costs are calculated on the checkout page.

Sales Rank

in USB Audio Interfaces

Bundles & offers

Zoom LiveTrak L-12 Card Bundle

$569

Zoom LiveTrak L-12 Rack-Kit Bundle

$645

Create your own bundle

starting from $575

Up to 5% discount

Zoom LiveTrak L-12 Starter Bundle

$649

Zoom LiveTrak L-12 Mic Set

$655

This is what customers who viewed this product bought

Focusrite Scarlett 2i2 3rd Gen

$129

bought

Focusrite Scarlett 18i20 3rd Gen

$429

270 Customer ratings

5 216 Customers 4 40 Customers 3 7 Customers 2 3 Customers 1 4 Customers

4.7 / 5

handling

features

sound

quality

Review guidelines

175 Reviews

can't think of any reason why you should not get this

Danieldrums 21.04.2020

I have been working with the Zoom for 6 months or so. I have no prior experience nor am I anything of a techy or sound specialist in any way but I managed to figure this thing out pretty easily. I did read quite some youtube films and the manual as well a few times though. I have only used it for recording our band, something we never did before and it works brilliantly. We record our whole band live with drums, guitars and vocals all at once. I have also tracked my drums separately to get the sound I want and I got it just the way I want it thanks to the great effects and the tuning possibilities. Also vocals and guitar separately have been done, beautiful sound again. I have not used it as a live mixer yet so can't speak to that. I have mixed the tracks down and then recorded it to the master, exported it as a WAV to the USB and uploaded it to share with the band. Super easy. I am not even using any computer. So so far, super happy with this purchase.

handling

features

sound

quality

Report

Do you believe this rating to be inaccurate or unacceptable for some reason? Please give us the reason for your assessment in the following text box and – if possible – your e-mail address for further questions.

The portable alrounder

Bogdan Octav 19.07.2018

I have purchased the Livetrak one year ago, for different unusual approaches to recording: In the park, in the rehearsal room, on jamsessions, etc., with a setup that will likely change on every occasion.
Let's go first of all to the limitations:
- no individual EQ buttons for each track, which requires some extra time in the beginning to switch through all the channels and see how the EQ is set
- Fader memory can lead to surprises. Especially the fact that the master fader is also memorized, can create a weird effect: You turn down the master, change the project, and all of the sudden everything goes into feedback, because the other project was saved with the master level all up. This can come to some surprise. A master fader override function would have been useful.
- No track bouncing possible
- no virtual tracks.

That being said, the sound quality is astonishing. The handling is quite intuitive, the results and the reliability excellent.
Giving it a little extra time can yield a wonderful sound, especially considering that the FX quality is very good.

I haven't used it too much as an interface, but I suppose it does its job well, too.

Awesome product, if more for live applications (like I use it) than for music production.

Go Zoom!

handling

features

sound

quality

Report

What An Amazing Piece Of Kit!

JimsabesT 30.01.2022

I only have the Zoom LiveTrack L-12 about a month now but it has excited and proved itself from first sight upon opening. I was intreagued reading about this compact mixer come recorder, it appeared to be the answer to several tasks I wanted to achieve. The first thing to amaze was the unbelieveable sound emmenating from its electronic innards, I have been involved in music on several fronts for over 55 years but I have never been so impressed with sound quality of this calibre in all of this time. Apart from being a king amongst the ranks of music production the quality, look and appeal of this little giant makes me proud to say that I own one. There are so many accolades, too numerous to mention here, that I just want to say if you are considering purchasing this carrat, this gem don't hesitate and purchase it at once. You won't regret it. As usual, Thomann are the other shining star with top class service and delivery. Well done and thank you Thomann.

handling

features

sound

quality

Report

Great mixer, some recording features could be improved

Plamen Sivov 14.10.2019

I bought the Zoom L-12 for our acoustic band and we have had great live gigs with the device. I also use it for occasional home recordings.

I liked the ease of use and the intuitive interface. As a long time Zoom products user the menus were very easy to use. The preamp quality is good enough for my recording needs.

I would really appreciate if the recording menu allowed for multiple takes of one single track - that's a feature common for other Zoom recorders and I really wonder why it's missing from the new flagman Zoom L-12. Probably this feature will not be of much use for most of the users who perform and record live with the unit, but for more elaborate home recordings it's really needed.

Apart from the above, highly recommended.

handling

features

sound

quality

Report
