Effect Pedal for Electric Guitar
- Pitch shifter
- 3 Harmony voices / delay lines with rhythmic time offset
- Tap Tempo function and synchronisation
- 12 Diatonic harmonies and chromatic pitch shifting
- Up to 16 presets via MIDI
- 24 Bit AD / DA with 32 bit floating point DSP
- Switchable headroom for guitar/line input level
- Tap Tempo functionality with separate temp increases for each voice
- Expression control possible for all effect parameters (also simultaneous)
- MIDI in / out / preset selection / external tap tempo available via EXP socket
- Analogue signal path for wet / dry mix
- Presets via external 4-preset switch (Meris Preset Switch, not included) or MIDI selectable
- Selectable bypass (True / Relay Bypass or Buffered)
- Key, Micro Tune, Mix, Pitch 1, Pitch 2, and Pitch 3 knobs
- Alt (Hold) button for activating alternative controller functions
- Mode Button for selecting the delay line arrangement (Dual / Dual + Series / Series / Pitch Feedback)
- Bypass footswitch
- Tap footswitch
- Status LEDs
- Metal housing
- 6.3 mm TRS input jack (switchable stereo / mono)
- 2x 6.3 mm mono latches (L / R) outputs
- 6.3 mm TRS Exp / Tap Tempo / External Footswitch / MIDI Jack
- Power supply via 9 V DC power supply unit with 2.1 x 5.5 mm barrel connector and polarity (-) inside (Power adapter not included)
- Current consumption: 150 mA
- Dimensions (W x D x H): 107 x 115 x 67 mm
- Weight: 410 g
- Made in USA
Note: Battery operation is not supported.
Note: Register your product at www.w-distribution.com/Warranty to extend the warranty to 4 years.
available since
July 2019
Item number
466213
sales unit
1 piece(s)
Effect Types
Pitchshifter
