Universal Audio Apollo x6 Heritage Edition

16 x 22 Thunderbolt 3 Audio Interface

  • Compatible with Thunderbolt 2 with optional Thunderbolt 2 to 3 adapter (not included)
  • Support of surround formats up to 7.1, with speaker calibration and downmix
  • Dual crystal clocking for low-jitter environment and clean, artifact-free recordings and stable stereo imaging
  • 6-Core SHARC DSP for internal UAD real-time processing
  • 2 Unison microphone preamplifiers
  • 2 Microphone inputs: XLR
  • 2 Hi-Z inputs: 6.3 mm jack
  • 6 Line inputs: 6.3 mm jack
  • 2 Monitor outputs: 6.3 mm jack
  • 6 Line outputs: 6.3 mm jack
  • S/PDIF coaxial input and output
  • 2 ADAT inputs and outputs
  • BNC Word clock input and output
  • 2 Stereo headphone ports: 6.3 mm jack
  • 2 Thunderbolt 3 ports
  • +48 V Phantom power
  • Pad
  • Low-cut
  • Phase reverse
  • Switch for monitor switchover
  • Function key can be assigned to Dim or Mono
  • LED Meter
  • Integrated talkback microphone
  • Support of surround formats up to 7.1, with speaker calibration and downmix
  • Dual crystal clocking for low-jitter environment and clean, artifact-free recordings and stable stereo imaging
  • For Mac/Windows
  • Up to 4 Apollos with Thunderbolt cascading connection
  • Design: 19" / 1U
  • Includes external power supply and software bundle Rackmount Heritage Edition & Realtime Analog Classics Plus

Further Information

Recording / Playback Channels 16x22
Number of Mic Inputs 2
Number of Line Inputs 6
Number of Instrument Inputs 2
Number of Line Outputs 8
Headphone Outs 2
Phantom Power Yes
Number of S/PDIF Connectors 1
Number of ADAT Connectors 2
AES/EBU Connectors 0
Number of MADI Connectors 0
Ethernet 0
Other Connectors No
MIDI Connectors No
Word Clock 1xIn, 1xOut
Max. Samplerate 192 kHz
Max. Resolution in Bit 24 bit
Bus-Powered No
Incl. Power Supply Yes
Windows Thunderbolt driver Yes
Thunderbolt Version 3
Width in mm 483 mm
Depth in mm 308 mm
Height in mm 44 mm
