Atomos Sumo19 SE


19" Live Switcher, Monitor and Recorder

  • With AtomHDR production monitor recording in 4K 12bit Raw, 10bit ProRes/DNxHR and a 1080p60 switcher/recorder
  • With 10 f-stops dynamic range and 10-bit processing
  • Supports all log formats as well as PQ and HLG
  • The durable aluminium chassis has ten threads (1/4 and 3/8 inch) distributed on the sides, top and bottom, and a rear-mountable VESA bracket for different configurations
  • For recording and playback of the audio source, an XLR audio connector, a 3.5 mm jack plug for headphones and built-in speakers are available
  • With the separately available battery plates, 2 V-Lock or Anton Bauer batteries can be used in tandem operation
  • Patented Continuous-Power technology allows batteries to be changed without loss of power
  • Easily connects to all standard SDI and HDMI sources and converts signals as required
  • Quad-SDI for connecting cameras with multiple 1.5 or 3G SDI outputs without the need for an intermediate converter
  • With HDMI 2.0, the Sumo supports 4Kp60 in and out as well as Genlock and LTC timecode
  • Records in Sony RAW, Canon RAW or Panasonic RAW via SDI with up to 12-bit 4kp30 as CDNG, ProResRAW or Apple ProRes / Avid DNxHR with up to 10-bit 4Kp60 (2kp240)
  • Record directly from the sensor at data rates of up to 3.2 Gbps with no loss of quality
  • Live switcher and recorder with up to 4x 1080p60 sources
  • 4x ISO recording and playback
  • Included in delivery: Atomos Sumo 19 SE, Master Caddy II
  • Power supply unit, mounting plate for 2 V-Mount adapter plates, VESA hole 10 x 10 cm, 2 feet incl. mounting screws

Technical data:

  • Weight without battery and stand: 5.45 kg
  • Dimensions without stand (W x H x D): 504 x 310 x 63 mm
  • Material: Aluminium alloy
  • Operating power: 75 watts
  • Compatible batteries: V-Lock / Anton Bauer via XLR terminal (optional mounting plates available) - recommended 95 Wh or larger
  • Input battery voltage: 14.4 nominal
  • DC Connector: 1 x DC In (12- 16.8 V)
  • Touchscreen: Size: 19", Resolution: 1920 x 1200
  • PPI: 120
  • Aspect ratio: 16:9 native
  • Colour range: REC.709 HDTV
  • Look up Table (LUT) support: 3D LUT (.cube format)
  • anamorphic De-Squeeze: 2x, 1.5x, 1.33x, Panasonic 8:3; Technology: SuperAtom IPS Panel (Capacitive Touch)
  • Calibration to Rec 709 with optional calibration unit
  • HDR: AtomHDR is supported
  • Supported log formats: Sony SLog2 / SLog3, Canon Clog / Clog2, Arri Log C, Panasonic Vlog, JVC JLog, Red LogFilm, FujiFilm Flog
  • Supported Gamuts: Sony SGamut / SGamut3 / SGamut3.cine, Canon Cinema / BT2020 /DCI P3 /DCI P3+, Panasonic V Gamut, Arri Alexa Wide Gamut
  • Bit depth: 10-bit (8+2 FRC)
  • Brightness: 1500nit (+/- 10% @ centre)
  • HDR Input: PQ and HLG
  • HDR Output: PQ and HLG
  • Video Input/Loop Out:
  • HDMI: 1x HDMI (2.0)
  • SDI: Quad Link 4x 3G SDI or 12G Single Link SDI
  • Signal: uncompressed true 10-bit or 8-bit 422 (depending on camera)
  • Video Output (Play Out):
  • HDMI: 1x HDMI (2.0): SDI: 1x 4K-SDI 12G/6G or HD-SDI 3G/1.5G
  • Signal: uncompressed true 10-bit or 8-bit 422 (depending on camera)
  • Supported loop out formats: HDMI to HDMI: 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60/100/120, 2160p 24/25/30/50/60, SDI to SDI: 720p 50/60, 1080i 50/60, 1080pSF 24/25/30/50/60/120, 2160p 24/25/30/30
  • Video signal conversion HDMI to SDI: 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60/100/120/200/240, 2160p 24/25/30/50/60
  • Video signal conversion SDI to HDMI: 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60/100/120/200/240, 2160p 24/25/30/50/60
  • Audio In/Out (48kHz PCM audio): HDMI: 2 or 8 channels, 24-bit, depending on camera, SDI: 12ch 48kHz 24-bit
  • Analogue audio: 2ch balanced XLR analogue in/out (direct XLR connection)
  • Dynamic range - >90 dB
  • Max. signal strength - +24 dBu
  • Max. analogue gain - +52 dB
  • 48 V phantom power for mic
  • Headphone Out: 3.5 mm
  • Supported media: 2.5" SSD/HDD compatible - depending on recording format/resolution and frame rate
  • Master Caddy Dock: 2.5" SATA to USB 2.0/3.0
  • Supported applications: FCPX/FCP7+/ Media Composer 5.0+ / Premiere 5.5+, EDIUS 6.0+ / Vegas Pro 10+ / Lightworks / Autodesk Smoke 2015.
  • XML support: FCPX XML native, FCPX/Adobe only limited, supported using third-party tools
available since July 2022
Item number 545309
sales unit 1 piece(s)
Design Field Recorder
Recorder Yes
Screen size [Inches] 19"
Screen resolution 1920 x 1200
Recording resolution 1080p
Record tracks 5
HDMI input Yes
SDI input Yes
HDMI Output Yes
SDI Output Yes
Streaming Function No
Battery Optional
Storage type SSD
Audio IN Yes
Audio Monitor Yes
Loudspeaker Yes
Scopes Yes
Tally No
Recording mount 1/4 "internal thread
