Cioks DC10

Multi Power Supply

  • Professional power adapter
  • 10 outputs configured in 8 galvanically isolated sections
  • 1600 mA
  • Short circuit protection on all outputs
  • LED's for all outputs
  • Temperature display
  • 3 x Outputs with 400 mA
  • 2 m Connector cable
  • Dimensions: 158 x 98 x 35 mm (without rubber feet)
  • Weight: 1.1 kg
  • Including 16 x flex cables and mounting kit for pedal boards

Configuration:

  • Output 1 - 4: 9 V DC / 100 mA
  • Output 5 + 6: 9 V DC / 200 mA
  • Output 7 + 8: 9 - 12 V DC / 400 mA
  • Output 9 + 10: 9 - 12 / 15 V DC / 400 mA

Further Information

DC/AC current DC
Output current in mA 1600 mA
9 V Yes
12 V Yes
18 V No
Secondary voltage No
Multi-output power supply Yes

Come up with your own creative bundle and save

If you order this product together with others as part of a bundle, you can save up to 5 % additionally!
Harley Benton SpaceShip 40 + Harley Benton Mounties + Cioks DC10 +
8 more
Configure bundle now
starting from $259
180 Customer Ratings
  • 5
  • 4
  • 3
  • 2
  • 1
4.9 /5
  • quality
Total
quality
The most versatile power supply
Arpie, 19.11.2015
It was a big concern to me what kind of power supply should I buy to feed all my pedals.

I have quite a lot of pedals in my pedalboard with different voltage & ampere requirement.

Just to give you a short insight, I have:
Morley Bad Horsie 2 Wah pedal, Sony DWZ wireless unit, Korg DT-10 tuner, Boss NS-2, Ibanez TS-9, DOD 250, TC Nova repeater, ADA midi switch, Decibel 11 Loop expander, Lehle SGoS, MXR EVH Phase 90, Hotone Reverb.

Couple of pedals needed relatively a huge 300mA supply, others needed a 12V. This situation obviously made the decision more difficult.

After checking literally everything on the market from T-Rex, Voodoo Lab, Carl Martin, Cioks, Dunlop.....I figured out that the best option for me would be the Cioks DC-10.

I must say I didn't regret my decision at all. Very robust unit, indestructible, 10 outlets in 8 isolated section, supplied with plenty of cables.
The only negative thing I can mention is that Cioks uses a RCA plug to connect the cables to the power unit, the normal typical DC plug would be more convenient. But as they put enough cable in the box I can't complain at all.

After connecting everything I realised that the annoying noise and hiss are gone.
The unit is small, easy to fit to any pedalboard, very well made, you can immediately feel the quality as soon as you hold it in your hand.

I really prefer that it has a proper main cable instead of an adapter.

Another useful feature: if something is wrong with any of the outlet (short circuit, incorrect voltage) the relevant red LED with blink accordingly to let you know the problem.

Well worth every penny!!!
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
quality
Cioks DC10
Donal F., 21.05.2015
I purchased this power supply as it can power my 15 volt Radial pedal, my 12 volt eventide H9 and still power another 6 x 9 volt pedals and can even double up 2 of the 9 volt outputs to power an 18 volt pedal. Extremely versatile and excellent build quality. Very flat footprint so easily fitted under a pedaltrain. All leads and adapters came with the unit also.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
quality
power supplied
Carl Ahn, 18.01.2021
High quality, pure solid clean power, well built and made to last.
And it feeds your power hungry pedals that need extra juice.

The only slightly troubling thing is getting the mains cable in and out the unit as it’s a tight squeeze.
However since I bought a uk power cable, which is more slim than the one that came with the unit, it's now easier to dissemble (when i need to, which is not too often anyway).

I don’t think I will ever need to buy another power supply, as this one will probably last forever.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
quality
I'm in love
12.05.2016
When I first held it, it felt heavy. That was good.
Then I unboxed it, and wow... the finish is amazing, the overall build is extremely professional, built like a tank - would probably survive one too...
The options are endless, you can power a massive board with this box, variable voltage, combine or isolate outputs, etc.. you name it.
It's so silent... no noise, great quality.
Two things to note:
1. If you planned to reuse flex cables from other power supplies, this uses RCA to connect, so forget it
2. There is only one daisy chain cable (with 2 outputs) so if you plan to do more chains, get the additional cables right away
Love it really, this will be a keeper and hope will last me a lifetime
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
$219 €180.67
The shipping costs are calculated on the checkout page.

The price in USD is a guideline price only!

Available immediately
Available immediately

This item is in stock and can be dispatched immediately.
