6-Channel audio interface
- 24-Bit / 192 kHz
- 2 Mic/Line/Instrument Combo Inputs: XLR/jack 6.3 mm
- 2 Line inputs: 6.3 mm Jack
- 4 Line outputs: 6.3 mm Jack DC-coupled
- S/PDIF input coaxial
- MIDI input and output
- 2 Stereo headphone outputs: 6.3 mm Jack
- USB 2.0
- +48V Phantom power
- Direct monitoring
- 4 LED VU meter (input)
- 1 LED VU meter (output)
- USB bus-powered (no power supply required)
- Compatible with Mac and PC (ASIO/Core Audio/DirectSound/WASAPI)
- Dimensions (W x H x D): 200 x 55.6 x 136.55 mm
- Weight: 850 g
- Includes Ableton Live Lite 10, MASCHINE Essentials, Monark, Replica, Mod Pack, Solid Bus Comp, Traktor LE 3, Complete Start and 25,- Euro voucher for the NI online shop
available since
June 2019
Item number
465732
sales unit
1 piece(s)
Recording / Playback Channels
6x6
Number of Mic Inputs
2
Number of Line Inputs
4
Number of Instrument Inputs
2
Number of Line Outs
4
Headphone Outs
2
Phantom power
Yes
Number of S/PDIF Connectors
1
Number of ADAT Connectors
0
Numer of AES/EBU Connectors
0
Number of MADI Connectors
0
Ethernet
0
Other Connectors
No
MIDI interface
Yes
Word Clock
No
Max. sample rate (kHz)
192 kHz
Max. resolution in bit
24 bit
USB Bus-Powered
Yes
Incl. power supply
No
USB Version
2.0
Width in mm
200 mm
Depth in mm
136,55 mm
Height in mm
55,6 mm
Connection Format
USB port Type B
Included in delivery
USB cable, software
Zero latency monitoring
1
