Compact Converter Including Power Supply
- Simultaneously converts SDI to HDMI and HDMI to SDI in all SD, HD and Ultra HD formats up to 2160p/60
- Conversion in both directions can be done in different SD, HD and Ultra HD video standards
- Equipped with full-size HDMI connectors and professional 12G-SDI connectors
- Works in all NTSC, PAL, 720p, 1080p, 1080PsF, 1080i and 2160p rates, including 4K DCI in 24/47,95/48
- Powered via USB-C socket
- 1 SDI video input
- SDI video outputs: automatic adjustment to HDMI video input
- 1 HDMI 2.0 video input
- 1 Type A HDMI 2.0 video output
- SDI rates: 270 Mbps, 1.5 G, 3 G, 6 G, 12 G
- Multirate support: Automatic detection of SD, HD, 2K, Ultra HD and 4K
- Updates, configurations and power supply: USB Type C
- Reclocking
- Camera Control: bidirectional signal conversion supports Blackmagic Camera Control and Tally
- Compatible operating systems: Mac Catalina 10.15, Mac Big Sur 11.1 or higher / Windows 10, 64 bit
- Power consumption: max. 5 W
- Operating voltage range: 4.40 - 5.25 V DC
- Dimensions: 81 x 59 x 25 mm
- Weight: 174 g
- Includes +5V universal power supply with plug adapters for most countries
Note: No copy-protected HDMI sources can be recorded via the HDMI input. Always check copyright before recording or distributing content.
available since
December 2021
Item number
531449
sales unit
1 piece(s)
Input
HDMI / SDI
Output
HDMI / SDI
