IK Multimedia AXE I/O

USB 2.0 Audio Interface

  • An audio interface especially designed for guitarists
  • 2 Inputs for instrument, line and microphone signals
  • With discrete Class A preamplifiers and switchable 48 V phantom power
  • Front-panel Hi-Z instrument inputs, including input 1 with Z-Tone (variable impedance)
  • JFET circuit for subtle harmonic additions and active switching for optimal operation with active pickups
  • Rear mic / line inputs via XLR / jack combo jacks
  • 1 Front panel amp output for re-amping
  • 4 Rear balanced line outputs on 1/4" TRS jack
  • 1 Stereo headphone jack on 6.3 mm stereo jack with its own control
  • Monitor and master volume controls
  • Built-in guitar tuner
  • Preset knob for controlling plugin parameters
  • 2 Inputs for expression pedals or footswitches for real-time control of virtual guitar effects
  • AD / DA conversion with 24 bit / 192 kHz
  • 117 dB dynamic range
  • MIDI in/out
  • With extensive software package (download) with AmpliTube 4 Deluxe, 10 T-RackS processors and Ableton Live Lite
  • System requirements: Windows 7 (64 bit), Mac OSX 10.11 (64 bit)
  • Weight: 1.3 kg
  • Dimensions: 238 x 211 x 53 mm
  • 1.5 m USB cable and power supply unit included

Further Information

Recording / Playback Channels 2x5
Number of Mic Inputs 2
Number of Line Inputs 2
Number of Instrument Inputs 2
Number of Line Outs 4
Headphone Outs 1
Phantom power Yes
Number of S/PDIF Connectors 0
Number of ADAT Connectors 0
Numer of AES/EBU Connectors 0
Number of MADI Connectors 0
Ethernet 0
Other Connectors No
MIDI interface Yes
Word Clock No
Max. sample rate (kHz) 192 kHz
Max. resolution in bit 24 bit
USB Bus-Powered No
Incl. power supply Yes
USB Version 2.0
Width in mm 238 mm
Depth in mm 211 mm
Height in mm 53 mm
