Arturia AudioFuse Studio
USB 2.0 Audio Interface
- 24-Bit / 192 kHz
- 18 Inputs and 20 outputs
- 4 Mic / line inputs: XLR / TRS combo socket
- 4 Line inputs: 6.3 mm TRS
- Phono input: Cinch
- Inputs: 1 - 4 switchable for instruments
- Inserts for inputs: 1 - 4: 6.3 mm TRS
- 4 Line outputs: 6.3 mm TRS
- 2 Aux outputs: 6.3 mm TRS for line signals and reamping
- S/PDIF coaxial input and output: Cinch
- Switchable to word clock
- 2 Headphone outputs: 6.3 mm TRS and 3.5 mm TRS
- 2 ADAT In / Out for maximum 8 channels @ 96 kHz Sampling Rate
- Integrated Bluetooth audio receiver
- Compatible with AAC and aptX
- Integrated monitor controller with dim / mute / mono function
- Monitor and source selection
- Integrated 3-fold USB hub for external devices
- USB-C socket
- Supports USB 2.0
- Compatible with Windows and Mac OS X
- Solid metal housing
- Dimensions: 265 x 160 x 72 mm
- Includes AudioFuse Creative Suite
Further Information
| Recording / Playback Channels | 18x20 |
|---|---|
| Number of Mic Inputs | 4 |
| Number of Line Inputs | 8 |
| Number of Instrument Inputs | 4 |
| Number of Line Outs | 6 |
| Headphone Outs | 2 |
| Phantom power | Yes |
| Number of S/PDIF Connectors | 2 |
| Number of ADAT Connectors | 4 |
| Numer of AES/EBU Connectors | 0 |
| Number of MADI Connectors | 0 |
| Ethernet | 0 |
| Other Connectors | 3x USB HUB |
| MIDI interface | No |
| Word Clock | 1xIn, 1xOut |
| Max. sample rate (kHz) | 192 kHz |
| Max. resolution in bit | 24 bit |
| USB Bus-Powered | No |
| Incl. power supply | Yes |
| USB Version | USB C |
| Width in mm | 265 mm |
| Depth in mm | 160 mm |
| Height in mm | 72 mm |
